HAWKER霍克® 牽引型蓄電池PzB型(帶螺栓堅固連接條)尺寸符合 IEC 254-2‘E’系列標準要求。
電池型號 |
標稱/額定容量 |
***大電池單體尺寸 |
帶電解液重量 |
||
長度 |
寬度 |
高度 |
|||
2 PzB 150 |
150 |
45 |
157.5 |
541 |
10.9 |
3 PzB 225 |
225 |
61 |
157.5 |
541 |
14.9 |
4 PzB 300 |
300 |
77 |
157.5 |
541 |
19.0 |
4 PzB 300A |
300 |
69.85 |
157.15 |
519 |
17.3 |
5 PzB 375 |
375 |
93 |
157.5 |
541 |
23.1 |
6 PzB 450 |
450 |
109 |
157.5 |
541 |
27.3 |
7 PzB 525 |
525 |
125 |
157.5 |
541 |
31.4 |
8 PzB 600 |
600 |
141 |
157.5 |
541 |
35.6 |
9 PzB 675 |
675 |
157 |
157.5 |
541 |
39.5 |
10 PzB 750 |
750 |
173 |
157.5 |
541 |
43.7 |
11 PzB 825 |
825 |
189 |
157.5 |
541 |
47.8 |
12 PzB 900 |
900 |
205 |
157.5 |
541 |
51.0 |
2 PzB 170 |
170 |
45 |
157.5 |
597 |
12.3 |
3 PzB 255 |
255 |
61 |
157.5 |
597 |
17.0 |
4 PzB 340 |
340 |
77 |
157.5 |
597 |
21.6 |
5 PzB 425 |
425 |
93 |
157.5 |
597 |
26.3 |
6 PzB 510 |
510 |
109 |
157.5 |
597 |
30.9 |
7 PzB 595 |
595 |
125 |
157.5 |
597 |
35.6 |
8 PzB 680 |
680 |
141 |
157.5 |
597 |
40.4 |
9 PzB 765 |
765 |
157 |
157.5 |
597 |
44.8 |
10 PzB 850 |
850 |
173 |
157.5 |
597 |
49.7 |
11 PzB 935 |
935 |
189 |
157.5 |
597 |
54.4 |
12 PzB 1020 |
1020 |
205 |
157.5 |
597 |
59.4 |
2 PzB 200 |
200 |
45 |
157.5 |
633 |
12.9 |
3 PzB 300 |
300 |
61 |
157.5 |
633 |
17.7 |
4 PzB 400 |
400 |
77 |
157.5 |
633 |
22.6 |
5 PzB 500 |
500 |
93 |
157.5 |
633 |
27.5 |
6 PzB 600 |
600 |
109 |
157.5 |
633 |
32.4 |
7 PzB 700 |
700 |
125 |
157.5 |
633 |
37.3 |
8 PzB 800 |
800 |
141 |
157.5 |
633 |
42.2 |
9 PzB 900 |
900 |
157 |
157.5 |
633 |
46.8 |
10 PzB 1000 |
1000 |
173 |
157.5 |
633 |
53.4 |
11 PzB 1100 |
1100 |
189 |
157.5 |
633 |
57.2 |
12 PzB 1200 |
1200 |
205 |
157.5 |
633 |
62.4 |
2 PzB 210 |
210 |
45 |
157.5 |
713 |
14.8 |
3 PzB 315 |
315 |
61 |
157.5 |
713 |
20.4 |
4 PzB 420 |
420 |
77 |
157.5 |
713 |
26.1 |
5 PzB 525 |
525 |
93 |
157.5 |
713 |
31.7 |
6 PzB 630 |
630 |
109 |
157.5 |
713 |
37.3 |
7 PzB 735 |
735 |
125 |
157.5 |
713 |
43.0 |
8 PzB 840 |
840 |
141 |
157.5 |
713 |
48.7 |
9 PzB 945 |
945 |
157 |
157.5 |
713 |
54.7 |
10 PzB 1050 |
1050 |
173 |
157.5 |
713 |
56.4 |
11 PzB 1155 |
1155 |
189 |
157.5 |
713 |
62.1 |
12 PzB 1260 |
1260 |
205 |
157.5 |
713 |
67.7 |
電池型號 |
標稱/額定容量 |
***大電池單體尺寸 |
帶電解液重量 |
||
長度 |
寬度 |
高度 |
|||
2 PzB 46 |
46 |
45 |
157.5 |
230 |
4.1 |
3 PzB 69 |
69 |
61 |
157.5 |
230 |
5.6 |
4 PzB 92 |
92 |
77 |
157.5 |
230 |
7.0 |
5 PzB 115 |
115 |
93 |
157.5 |
230 |
8.5 |
6 PzB 138 |
138 |
109 |
157.5 |
230 |
10.0 |
2 PzB 64 |
64 |
45 |
157.5 |
292 |
5.4 |
3 PzB 96 |
96 |
61 |
157.5 |
292 |
7.3 |
4 PzB 128 |
128 |
77 |
157.5 |
292 |
9.2 |
5 PzB 160 |
160 |
93 |
157.5 |
292 |
11.3 |
6 PzB 192 |
192 |
109 |
157.5 |
292 |
13.2 |
7 PzB 224 |
224 |
125 |
157.5 |
292 |
15.2 |
8 PzB 256 |
256 |
141 |
157.5 |
292 |
17.2 |
2 PzB 84 |
84 |
45 |
157.5 |
358 |
6.9 |
3 PzB 126 |
126 |
61 |
157.5 |
358 |
9.4 |
4 PzB 168 |
168 |
77 |
157.5 |
358 |
11.9 |
5 PzB 210 |
210 |
93 |
157.5 |
358 |
14.5 |
6 PzB 252 |
252 |
109 |
157.5 |
358 |
17.1 |
7 PzB 294 |
294 |
125 |
157.5 |
358 |
19.7 |
8 PzB 336 |
336 |
141 |
157.5 |
358 |
22.2 |
2 PzB 110 |
110 |
45 |
157.5 |
428 |
8.4 |
3 PzB 165 |
165 |
61 |
157.5 |
428 |
11.5 |
4 PzB 220 |
220 |
77 |
157.5 |
428 |
14.6 |
5 PzB 275 |
275 |
93 |
157.5 |
428 |
17.8 |
6 PzB 330 |
330 |
109 |
157.5 |
428 |
20.9 |
7 PzB 385 |
385 |
125 |
157.5 |
428 |
24.0 |
8 PzB 440 |
440 |
141 |
157.5 |
428 |
27.2 |
9 PzB 495 |
495 |
157 |
157.5 |
428 |
30.3 |
10 PzB 550 |
550 |
173 |
157.5 |
428 |
33.3 |
11 PzB 605 |
605 |
189 |
157.5 |
428 |
36.6 |
12 PzB 660 |
660 |
205 |
157.5 |
428 |
40.0 |
2 PzB 130 |
130 |
45 |
157.5 |
484 |
9.6 |
3 PzB 195 |
195 |
61 |
157.5 |
484 |
13.2 |
4 PzB 260 |
260 |
77 |
157.5 |
484 |
16.8 |
5 PzB 325 |
325 |
93 |
157.5 |
484 |
20.5 |
6 PzB 390 |
390 |
109 |
157.5 |
484 |
24.1 |
7 PzB 455 |
455 |
125 |
157.5 |
484 |
27.7 |
8 PzB 520 |
520 |
141 |
157.5 |
484 |
31.4 |
9 PzB 585 |
585 |
157 |
157.5 |
484 |
35.0 |
10 PzB 650 |
650 |
173 |
157.5 |
484 |
38.5 |
11 PzB 715 |
715 |
189 |
157.5 |
484 |
42.4 |
12 PzB 780 |
780 |
205 |
157.5 |
484 |
46.2 |
電池蓋頂部高度=電池***大高度-30mm
HAWKER WATER LESS 霍克叉車蓄電池48V6PZM480
