EMERSON/艾默生 ASCO電磁閥 S290系列電磁閥
點擊圖片查看原圖
品牌： EMERSON/艾默生 ASCO
型號： S290系列電磁閥
單價： 面議
所在地： 上海
有效期至： 長期有效
最后更新： 2018-05-23 17:48
瀏覽次數： 383
店鋪基本資料信息
  • 美國ASCO電磁閥
  • 聯系人趙尉宏(先生)
  • 會員 [當前離線]
  • 電話13262790359
  • 地址上海市寶山區富聯一路98弄6號

 產品詳細說明
 EMERSON/艾默生 ASCO電磁閥 S290系列電磁閥

ANGLE SEATED VALVES
CLAMP or Butt Welding connection
stainless steel body
DN 10 to 65

FEATURES
• Valve with clamp type connection to ISO 2852 for quick disconnection, a system
commonly used in the food processing industry or with butt welding connection to
ISO 6761 for stainless steel pipe to ISO 1127
• CLAMP valve body pickled in nitric/fluoric acid bath
(NET-INOX passivation treatment)
• High flow due to angled seat design
• Anti-waterhammer design (fluid entry under the disc)
• Vacuum operation up to 10-2 mbar
• Wide range of piston-type operators (32 - 50- 63 - 90 -125 mm dia.) rotatable
through 360°, for maximum performance at different minimum pilot pressures
• High performance, maintenance-free stuffing box
• The valves satisfy Pressure Equipment Directive 97/23/EC, category 1 (DN > 25)
or article 3.3 (DN≤ 25)
 s290-1s290-2
