威德福五缸工業泵 W300H W300M W300L

點擊圖片查看原圖
品牌: 威德福Weatherford
功率: 224KW
行程: 127mm
單價: 面議
所在地: 上海
有效期至: 長期有效
最后更新: 2018-04-05 11:42
瀏覽次數: 363
詢價
店鋪基本資料信息

產品詳細說明
威德福Weatherford五缸工業泵 W300 W300H W300M W300L

Pump Specifications:
Rated (HP, kW) 300 224
Stroke length (in., mm) 5 127
Maximum discharge pressure (PSI, Bar)
W300H 5,000 345
W300M 3,000 207
W300L 1,650 114
Rated rod load (lb, kg) 10,700 4,853
API-674 speed, RPM 310
Maximum speed, RPM 400
Minimum speed, RPM 100
Crankshaft dimensions (in., mm)
Diameter 4.875 124
Length (long) 11.62 295
Length (short) 5.62 143
Keyway, width × depth (in., mm) 1.25 × .62 32 × 16
Oil capacity (gal, l)
Pump 12 46
Reducer (varies with ratio) 3.5 to 6.5 13 to 25
Weight (lb, kg); estimates only
Pump
W300H 6,840 3,103
W300M 6,750 3,062
W300L 7,000 3,175
Reducer 1,100 499
Mechanical efficiency 90%

Flange Connections:
Pump Model              Discharge Connection Sizes (in., mm)         Suction Connection Sizes (in., mm)
W300H                                  2 (50.8) ANSI 2500 RJ                                         6 (152.4) NSD 600 RJ*
W300M                                  3 (76.2) NSD 5000 RJ*                                        6 (152.4) NSD 600 RJ*
W300L                        4 (101.6) API 2000 RJ 8 (203.2) ANSI 150 FF
*One blind and one weld neck flange provided

Standard Equipment:
• Cast aluminum-bronze, forged duplex stainless steel, or forged carbon steel fluid ends
• Aluminum-bronze or duplex stainless steel stuffing boxes
• Various valve designs offered per fluid end style
• Tungsten carbide coated plungers over stainless steel base or solid ceramic plungers
• Double extended crankshaft
• Multiple plunger packing arrangements offered

Optional Accessories
• Weatherford bolt on gear reducers (ratios)
––2.27:1  ––2.89:1  ––3.25:1  ––3.36:1  ––3.69:1  ––4.38:1  ––4.84:1  ––5.56:1
• Packing lubricators
• Customized plunger packing arrangements
• Power end lube system
• Complete pump packages
