應用范圍

Liquids and bulk solids, not abrasive

VEGACAP 66物位測量傳感器能在所有工業環境中廣泛應用。 全絕緣的測量電極用于導電液體以及粒料測量。 機械結構久經考驗，保證極高的功能安全性。

您的獲益

• Simple planning due to variable switching point
• Savings through simple mounting and setup
• Long lifetime and low maintenance requirement through robust mechanical construction

技術參數

Measuring range - Distance

32 m

Process temperature

-50 ... 150 °C

Process pressure

-1 ... 40 bar

Version

§ PTFE insulated cable ø 8 mm with gravity weight

§ PTFE-insulated cable ø 8 mm with gravity weight and screening tube

Materials,-wetted-parts

§ PTFE

§ 316L

§ Steel C22.8

Threaded-connection

≥ G1, ≥ 1 NPT

Flange connection

≥ DN40, ≥ 1½"

Seal-material

no media contact

Housing-material

§ Plastic

§ Aluminium

§ Stainless steel (precision casting)

§ Stainless steel (electropolished)

Protection-rating

§ IP 66/IP 68 (0.2 bar)

§ IP 66/IP 67

§ IP 66/IP 68 (1 bar)

Output

§ Relay (DPDT)

§ Contactless electronic switch

§ Transistor (NPN/PNP)

§ Two-wire

Ambient temperature

-40 ... 80 °C
