●*大制品容積（Max. Volume of product）-----------------------------------------------160L
●擠出系統(Extrusion)
螺桿直徑Screw diameter------------------------------------------------------------------------100mm
螺桿長徑比Screw L/D---------------------------------------------------------------------------30:1
塑化能力（HDPE)Plasticizing capacity--------------------------------------------------------240kg/h
機筒加熱段數Heating zone------------------------------------------------------------------------5
機筒加熱功率Heating power----------------------------------------------------------------------30kw
擠出電機功率Extrusion power--------------------------------------------------------------------90kw
●模頭 Mould head
*大儲料容積 Max accumulate volume---------------------------------------------------------16L
口模直徑 Diameter of mouth die--------------------------------------------------------------100~300mm
模頭加熱段數 Heating zone-----------------------------------------------------------------------5
模頭加熱功率 Heating power----------------------------------------------------------------------35kw
●合模裝置 Clamping system
模板尺寸（寬×高）Size of mould size(W×H)---------------------------------------1100×1100mm
模板間距 Mold platen opening stroke-----------------------------------------------------600~140mm
鎖模力 Clamping force---------------------------------------------------------------------------550kn
●液壓系統 Hydraulic system
大泵額定壓力 Rating pressure of large pump-----------------------------------------------------12mpa
小泵*高壓力 Rating pressure of small pump----------------------------------------------------18mpa
液壓泵電機功率 Motor power of hydraulic pump------------------------------------------------37kw
●壁厚控制液壓伺服系統 Thickness controller hydraulic servo system
額定壓力 Rating pressure-----------------------------------------------------------------------------10mpa
額定流量 Rating flow------------------------------------------------------------------------------23L/min
液壓泵電機功率 Motor power of hydraulic pump------------------------------------------------4kw
●氣動系統 Pneumatic system
氣源壓力 Air source pressure----------------------------------------------------------------------0.7mpa
工作壓力 Work pressure----------------------------------------------------------------------------0.6mpa
耗氣量 Air consumption-------------------------------------------------------------------------1.1m³/min
●水源 Water supply
供水壓力 Pressure of water supply---------------------------------------------------------------0.3mpa
●電源 Electric power
電壓 Voltage----------------------------------------------------------------------------------AC380v±10%
頻率 Frequency-----------------------------------------------------------------------------------------50hz
線制 Connecting cable---------------------------------------------三相四線制 Three phase four wires
總額定功率 Gross rating power-----------------------------------------------------------------196kw
平均能耗 Average energy consumption------------------------------------------------------105kw/h
●機器重量 Machine weight---------------------------------------------------------------------20ton
●機器外形尺寸(長×寬×高) Outline dimension(L×W×H)------------------------8.7×4.2×5m
